2835mil chip: This WB economical street light adopts Sanan's 2835mil chip, which has the characteristics of energy saving, point saving, high lumen, low light decay, and RA>70.
Waterproof design: The whole lamp can reach the waterproof IP65 level, which is suitable for environments with high protection requirements, relatively high humidity and harsh environment. It is a truly waterproof product.
Environmental protection: complete power, high lumens, high efficiency, high CRI, low power consumption, environmental protection, high luminous flux, compared with traditional street lamps, the energy saving is more than 80%, the installation is particularly convenient, the warranty is 2 years, and the service life reaches 30,000 hours .
Driving: This economical street light adopts economical isolated or non-isolated driver.
Item NO | SL2-3-30WB | SL2-3-50WB | SL2-3-100WB | SL2-3-150WB | SL2-3-200WB |
Watt(W) | 30 | 50 | 100 | 150 | 200 |
Lamp Luminous Efficiency(LM/W) | 100 | 100 | 100 | 100 | 100 |
Lamp Luminous Flux(lm) | 3000 | 5000 | 10000 | 15000 | 20000 |
Body Size(mm) | 310*124*40 | 400*139*50 | 520*183*50 | 620*185*70 | 638*220*70 |
Input Voltage(V) | AC85-265V | ||||
Color Temperature(CCT) | 3000-4000-6500K | ||||
IES | IES available | ||||
Beam Angle(°) | 75*150° | ||||
Work Temperature(°) | (-30,45) | ||||
Working Lifetime(H) | 25000Hours | ||||
Lamp Body Material | Aluminum Die-casting | ||||
Lens | PC Lens | ||||
IK | IK08 | ||||
SPD | 10KV | ||||
IP Rating | IP65 | ||||
Driver Brand | Normal driver | ||||
LED Chip | Chinese Sanan 2835mil | ||||
CRI(Ra>) | 70 | ||||
Certification | CE | ||||
Warranty(Years) | 2years | ||||
Color | Grey | ||||
PF(>) | 0.9 |
